EATON CBRPM140 100A 1-PHASE NEMA 1 40/80-SPACE MAIN BREAKER LOAD CENTER
MFR Part #: CBRPM140
SKU #: 1303278
Brand: EATON
UPC: 621037006768
Eaton CBRPM140 Type BR Main Breaker Loadcenter, Canadian PON Loadcenter, 40 Circuits, 100 A, 1-Phase, White
Attributes
Resources
Amperage Rating:121 A
Breaker Type:BRH
Bus Material:Aluminum
Bus Rating:125 A
Color:White
Country Of Origin:Canada
Dimensions:34-1/8 in H x 14-3/8 in W x 3-7/8 in D
Enclosure Type:NEMA 1
Height:34.13 in
Interrupt Rating:22 kA, 25 kAIC
Made In Canada:Yes
Material:Steel
Mounting Type:Flush, Surface
Number of Circuits:40
Number of Spaces:80
Phase:1, 1 ph
Voltage Rating:120/240 VAC
Weight:35 lb
Width:14.38 in
Wire Size:8 to 1/0 AWG
Wiring Configuration:3-Wire
Attributes
Amperage Rating: 121 A
Breaker Type: BRH
Bus Material: Aluminum
Bus Rating: 125 A
Color: White
Country Of Origin: Canada
Dimensions: 34-1/8 in H x 14-3/8 in W x 3-7/8 in D
Enclosure Type: NEMA 1
Height: 34.13 in
Interrupt Rating: 22 kA, 25 kAIC
Made In Canada: Yes
Material: Steel
Mounting Type: Flush, Surface
Number of Circuits: 40
Number of Spaces: 80
Phase: 1, 1 ph
Voltage Rating: 120/240 VAC
Weight: 35 lb
Width: 14.38 in
Wire Size: 8 to 1/0 AWG
Wiring Configuration: 3-Wire
