WEIL MCLAIN SVF-750 SS CNDSNG 750000BTU VERTICAL NG BOILER
Product Details
Attributes
Features
Resources
Weil-McLain® High-Efficiency Condensing Gas Fired Water Boiler, 120 V, 11.7 A, 60 Hz Frequency, 1 ph, 157 to 785 MBtu/hr BTU, 17 to 75 gpm Flow Rate, 160 psi Pressure, Liquid Propane Gas, Natural Gas Fuel, Chimney/Breeching/Vent Size: 6 in Dia x 100 ft L, Ignition System: Direct Spark, Net BTU Rating: 657 MBtu/hr, Stainless Steel, 50 to 190 deg F, Dimensions: 52.9 in L x 31.7 in W x 79.4 in H
- Up to 97.1% thermal efficiency
- ASME certified stainless steel fire tube heat exchanger and shell
- "Clover" tube design for maximum heat transfer
- 30 psi relief valve
- Pickled and passivated welded design
- Modulating, low emissions burner design
- Down to <20 ppm NOx emission
- 5:1 turndown ratio
- Low gas pressure operation
- Variable speed blower assembly
- Venturi mixing system
- Negative pressure regulated gas valve
- 50 VA transformer
- Temperature and pressure gauge
- Outdoor water temperature sensor
- Outlet and inlet water temperature sensor
- Flue gas temperature sensor
- System water temperature sensors - immersion style, supply and return
- Complete jacket assembly with fully removable jacket, rugged, steel frame and panels, manual reset push button through display
- Easy installation/serviceability
