DAHL 621-01-04-PK2 Image 1

DAHL 621-01-04-PK2 1/2IN SWT/MIP SEDIMENT DRAIN

MFR Part #: 621-01-04-PK2
SKU #: 1300840
Brand: dahl
UPC: 400052166462
dahl mini-ball™ 621-01-04-PK2 Hose and Boiler Drain Valve, 1/2 in, Female Solder or MIP x Male Hose, 250 psi, 250 deg F
Limited
Plumbing and Heating Applications
cCSAus Certified|NSF/ANSI/CAN 61/372|UPC Certified

dahl mini-ball™ Hose and Boiler Drain Valve, 1/2 in Nominal, Female Solder or MIP x Male Hose Connection, 250 psi, 1 in Top to Inlet Center, Brass Body, PTFE Seal, Zinc Handle, EPDM/FKM Softgoods, 1.8 Cv Flow Coefficient (Cv), 250 deg F, Lead-Free, Finish: Rough

dahl valves and fittings are designed and manufactured in Canada and backed by our lifetime transferable warranty. Made with 100% North American materials, specifically with premium quality US lead-free brass, every dahl valve is tested for quality before leaving the plant. More than a valve, dahl offers a lifetime of reliability.

Product Details

dahl mini-ball™ Hose and Boiler Drain Valve, 1/2 in Nominal, Female Solder or MIP x Male Hose Connection, 250 psi, 1 in Top to Inlet Center, Brass Body, PTFE Seal, Zinc Handle, EPDM/FKM Softgoods, 1.8 Cv Flow Coefficient (Cv), 250 deg F, Lead-Free, Finish: Rough

dahl valves and fittings are designed and manufactured in Canada and backed by our lifetime transferable warranty. Made with 100% North American materials, specifically with premium quality US lead-free brass, every dahl valve is tested for quality before leaving the plant. More than a valve, dahl offers a lifetime of reliability.

Attributes

Nominal Size: 1/2 in
Body Material: Brass
Connection Type: Female Solder or MIP x Male Hose
Finish: Rough
Flow Coefficient (Cv): 1.8 Cv
Handle Material: Zinc
Inlet Connection: MIP or 1/2 Fem. Solder
Inlet Size: 1/2 in
Lead-Free/Contains Lead: Lead-Free
Material: Lead-Free Brass
Operation: Plated Handle
Outlet Connection: Male Hose
Pattern: Angle
Pressure Rating: 250 psi
Seal Material: PTFE
Softgoods Material: EPDM/FKM
Temperature Rating: 250 deg F
Top to Inlet Center: 1 in

Features

  • Every valve is tested before leaving our factory
  • No need to dismantle before soldering
  • Made in Canada with North American materials

Resources

Catalog
Full Engineering Drawing
