CALEFACTIO MAN11-SS100 1IN FIP 11-LOOP STAINLESS STEEL 304 MANIFOLD
MFR Part #: MAN11-SS100
SKU #: 1303255
Brand: Calefactio
UPC: 400052295988
Calefactio MAN11-SS100 Caltherm Pro Stainless Steel Manifold Kit, 11-Loop, 1 in Connection, 23.1 gpm, 125 psi, 230 deg F
Product Details
Attributes
Features
Resources
Calefactio’s stainless steel manifold kit is delivered pre-assembled and ready to install. Headers are offered in 14 models (2 to 15 loops) with a maximum flowrate of 31.5 gallons per minute (GPM). They come in pair and the kit includes supply and return headers, isolating valve, wall support, flowmeter, surface thermometer (0-80°C), air purger and drain. The integrated flowmeters allow the user to adjust the flow easily in each loop. Circuit isolation valves are also compatible with 24 V actuators from Calefactio (#AC24VNC). The manifolds are delivered pre-assembled and ready to install.
Maximum Flow Rate:23.1 gpm
Maximum Pressure:125 psi
Maximum Temperature:230 deg F
Weight:15.8 lbs
- Headers with 1” connection
- Made of 304 stainless steel
- Pre-assembled on wall support for easy installation
- Integrated flowmeters (8 LPM / 2.1 GPM per loop)
- Maximum pressure: 125 psi / 862 kPa
- Maximum temperature: 230°F / 110°C
- Provided with air purger and drain
- Compatible with Calefactio 24 volt actuator (#AC24NC)
- Compatible with ethylene and propylene glycol up to a maximum of 50% concentration
- Possibility to isolate each loop with isolating valve and balancing valve
- 2-way NPT ball valve with integrated thermometer
Product Details
Calefactio’s stainless steel manifold kit is delivered pre-assembled and ready to install. Headers are offered in 14 models (2 to 15 loops) with a maximum flowrate of 31.5 gallons per minute (GPM). They come in pair and the kit includes supply and return headers, isolating valve, wall support, flowmeter, surface thermometer (0-80°C), air purger and drain. The integrated flowmeters allow the user to adjust the flow easily in each loop. Circuit isolation valves are also compatible with 24 V actuators from Calefactio (#AC24VNC). The manifolds are delivered pre-assembled and ready to install.
Attributes
Maximum Flow Rate: 23.1 gpm
Maximum Pressure: 125 psi
Maximum Temperature: 230 deg F
Weight: 15.8 lbs
Features
- Headers with 1” connection
- Made of 304 stainless steel
- Pre-assembled on wall support for easy installation
- Integrated flowmeters (8 LPM / 2.1 GPM per loop)
- Maximum pressure: 125 psi / 862 kPa
- Maximum temperature: 230°F / 110°C
- Provided with air purger and drain
- Compatible with Calefactio 24 volt actuator (#AC24NC)
- Compatible with ethylene and propylene glycol up to a maximum of 50% concentration
- Possibility to isolate each loop with isolating valve and balancing valve
- 2-way NPT ball valve with integrated thermometer
