LITHONIA 167FMU TANDEM T8 GEN-PURPOSE 4 LAMPS 32W TL232 MV
MFR Part #: TL232 MV
SKU #: 1224526
Brand: Acuity Brands | Lithonia Lighting®
UPC: 745975276387
Lithonia Lighting® TL232 MV TL Series Contractor Select General Purpose Industrial Tandem Linear Strip Light, (4) Lamps T8 Lamp, 120 to 277 VAC, High Gloss Baked White Enamel Housing
Limited
Light Duty Areas Closet/Storage Room, Manufacturing, Residential, Retail, Warehouse/Storage, Corridor and Light Commercial
UL Listed | CSA Certified
Product Details
Attributes
Features
Resources
Lithonia Lighting®, TL232 MV, Tandem Linear Strip Light, Contractor Select General Purpose Industrial, Series: TL Series, 120 to 277 VAC, T8 Lamp, 32 W Lamp, 4 Lamps, 3500 K Color Temperature, 70 CRI, Instant Start Electronic Ballast, Surface/Suspended Mounting, Steel Housing Material, High Gloss Baked White Enamel Housing Finish, 96 in L x 12 in W x 4 in D Dimensions
Color Temperature:3500 K
Ballast Type:Instant Start Electronic
Color Rendering Index (CRI):70
Dimensions:96 in L x 12 in W x 4 in D
Housing Finish:High Gloss Baked White Enamel
Housing Material:Steel
Insulation Type:Class B
Lamp Type:T8
Lamp Wattage:32 W
Mounting Type:Surface/Suspended
Number of Lamps:4
Series:TL Series
Type:Contractor Select General Purpose Industrial
Voltage Rating:120 to 277 V AC
- Tandem double length unit
- Sturdy combination reflector and channel cover constructed of die formed cold rolled steel and secured by quarter turn latch for easy access to wire way
- Screw-on endplates
- Accepts plug in option for 1, 2 or 3 primary circuit
- Five-stage iron phosphate pre-treatment ensures superior paint adhesion and rust resistance
- Reflector and channel finished with a high gloss baked white enamel
- Solid top or aperture 8% uplight available, both reflectors are die-embossed
- Thermally protected, resetting, class-P, HPF, non-PCB ballast
- Sound rating depends on lamp/ballast combination
- Suitable for damp location
- Intended for mounting heights up to 16 ft requiring low to medium light levels
Product Details
Lithonia Lighting®, TL232 MV, Tandem Linear Strip Light, Contractor Select General Purpose Industrial, Series: TL Series, 120 to 277 VAC, T8 Lamp, 32 W Lamp, 4 Lamps, 3500 K Color Temperature, 70 CRI, Instant Start Electronic Ballast, Surface/Suspended Mounting, Steel Housing Material, High Gloss Baked White Enamel Housing Finish, 96 in L x 12 in W x 4 in D Dimensions
Attributes
Color Temperature: 3500 K
Ballast Type: Instant Start Electronic
Color Rendering Index (CRI): 70
Dimensions: 96 in L x 12 in W x 4 in D
Housing Finish: High Gloss Baked White Enamel
Housing Material: Steel
Insulation Type: Class B
Lamp Type: T8
Lamp Wattage: 32 W
Mounting Type: Surface/Suspended
Number of Lamps: 4
Series: TL Series
Type: Contractor Select General Purpose Industrial
Voltage Rating: 120 to 277 V AC
Features
- Tandem double length unit
- Sturdy combination reflector and channel cover constructed of die formed cold rolled steel and secured by quarter turn latch for easy access to wire way
- Screw-on endplates
- Accepts plug in option for 1, 2 or 3 primary circuit
- Five-stage iron phosphate pre-treatment ensures superior paint adhesion and rust resistance
- Reflector and channel finished with a high gloss baked white enamel
- Solid top or aperture 8% uplight available, both reflectors are die-embossed
- Thermally protected, resetting, class-P, HPF, non-PCB ballast
- Sound rating depends on lamp/ballast combination
- Suitable for damp location
- Intended for mounting heights up to 16 ft requiring low to medium light levels
