HUBBELL 2027FBAR RACO 1-GANG PLASTIC VAPOUR BARRIER CEILING BOX
Product Details
Attributes
Features
Resources
RACO® tradeSELECT® Cable Box, 1 Gang, 4 in Dia, Round, Ceiling Mount, 27 cu-in, Plastic Resin, 2-3/4 in H x 5-1/4 in W x 2-5/8 in D
Canadian made and engineered for over 30 years, Hubbell® Banana Box™ are designed to provide the fastest and easiest installation in the industry. Each Banana Box™ is engineered to provide the greatest amount of versatility on the market. Installation can be done using virtually any type of fastener and each box incorporates many labor saving features. A genuine Hubbell® Banana Box™ is distinguished by the bright yellow color, providing high visibility when installing and wiring in low light levels.
- Superior mounting methods to accommodate virtually any screw and/or nail installation
- Ground screw spacing positioned in-line with wire entry, easy to wrap ground wires with fingers or pliers
- Advanced overmolded ground providing superior support for light fixtures and wall sconces
- A full 'U' shaped ground strap that provides a continuous ground
- Engineered with pre-installed device mounting screws (2) 8-32 x 1 in allows quicker installation
- Bottom ground screw location complete with 2 ground screws to accommodate quick installation
- Large cubic capacity over 27 cu-in capacity allows ease to terminate and accommodate conductors, wire nuts and grounding
- Centering V notches saves installation time by assuring consistent box positioning
- 4 oversize 1/2 in drywall tabs with score lines to break-off for thicker drywall
- 2 x 45 deg mounting holes are located inside and closed OFF giving the installer more mounting options
- Star shape openings to secure and hold screws or nails in place while working overhead
- Molded from high strength plastic resin
- Hands free installation for 1/2, 5/8 or 3-gang/4 in drywall
- Vapor/air barrier flange and integral wire entry seal provides superior energy savings and quick installation
- Self-clamping wire entry tabs
- Front mounted grounding screw with combination straight/Robertson head
- The box provides flexibility by offering universal mounting brackets, with screw and nail guides
- Stainless steel type wall plate
Product Details
RACO® tradeSELECT® Cable Box, 1 Gang, 4 in Dia, Round, Ceiling Mount, 27 cu-in, Plastic Resin, 2-3/4 in H x 5-1/4 in W x 2-5/8 in D
Canadian made and engineered for over 30 years, Hubbell® Banana Box™ are designed to provide the fastest and easiest installation in the industry. Each Banana Box™ is engineered to provide the greatest amount of versatility on the market. Installation can be done using virtually any type of fastener and each box incorporates many labor saving features. A genuine Hubbell® Banana Box™ is distinguished by the bright yellow color, providing high visibility when installing and wiring in low light levels.
Attributes
Features
- Superior mounting methods to accommodate virtually any screw and/or nail installation
- Ground screw spacing positioned in-line with wire entry, easy to wrap ground wires with fingers or pliers
- Advanced overmolded ground providing superior support for light fixtures and wall sconces
- A full 'U' shaped ground strap that provides a continuous ground
- Engineered with pre-installed device mounting screws (2) 8-32 x 1 in allows quicker installation
- Bottom ground screw location complete with 2 ground screws to accommodate quick installation
- Large cubic capacity over 27 cu-in capacity allows ease to terminate and accommodate conductors, wire nuts and grounding
- Centering V notches saves installation time by assuring consistent box positioning
- 4 oversize 1/2 in drywall tabs with score lines to break-off for thicker drywall
- 2 x 45 deg mounting holes are located inside and closed OFF giving the installer more mounting options
- Star shape openings to secure and hold screws or nails in place while working overhead
- Molded from high strength plastic resin
- Hands free installation for 1/2, 5/8 or 3-gang/4 in drywall
- Vapor/air barrier flange and integral wire entry seal provides superior energy savings and quick installation
- Self-clamping wire entry tabs
- Front mounted grounding screw with combination straight/Robertson head
- The box provides flexibility by offering universal mounting brackets, with screw and nail guides
- Stainless steel type wall plate
