TEMPERATURE CONTRIL JOHNSON CONTROLS A19AAF-12C
MFR Part #: A19AAF-12C
SKU #: 1054005
Brand: Johnson Controls
UPC: 785028083425
Johnson Controls A19AAF-12C Temperature Control, 120/208/240 VAC, 15 A at 120 VAC, 3 A at 240 VAC Full Load, 1 Stages
For temperature control in HVAC/R applications
UL E6688, CSA LR948/4813 02
Product Details
Attributes
Features
Resources
Johnson Controls Penn Temperature Control, Series: A19, 15 A at 120 VAC, 3 A at 240 VAC Full Load, 120/208/240 VAC, Configuration: SPDT, Switching Action: Open/Close on Rise, 1 Stages, 10 ft Capillary Length, Sensing Element: Bulb, 6 A Full Load and 36 A Locked Rotor at 120 VAC, 3.4 A Full Load and 20.4 A Locked Rotor at 208 VAC, 3 A Full Load and 18 A Locked Rotor at 240 VAC, 10 A Non Inductive at 24 - 277 VAC, 125 V-A at 24 - 277 VAC Pilot Duty Contact, 1 -Switch, 3.5 deg F Differential, Temperature Settings: 25 - 255 deg F, Flat Surface Mounting, Galvanized Steel Enclosure, Gray, 2-1/8 in L, 4-3/8 in H, 1-13/16 in W, 275 deg F
Amperage Rating:15 A at 120 VAC, 3 A at 240 VAC Full Load
Capillary Length:10 ft
Color:Gray
Configuration:SPDT
Contact Rating:6 A Full Load and 36 A Locked Rotor at 120 VAC, 3.4 A Full Load and 20.4 A Locked Rotor at 208 VAC, 3 A Full Load and 18 A Locked Rotor at 240 VAC, 10 A Non Inductive at 24 - 277 VAC, 125 V-A at 24 - 277 VAC Pilot Duty
Differential Temperature:3.5 deg F
Height:4-3/8 in
Length:2-1/8 in
Material:Galvanized Steel Enclosure
Mounting Type:Flat Surface
Number of Switches:1
Sensing Element:Bulb
Series:A19
Stages:1
Switching Action:Open/Close on Rise
Temperature Rating:275 deg F
Temperature Settings:25 - 255 deg F
Voltage Rating:120/208/240 VAC
Width:1-13/16 in
- A19 Series controls are single-stage temperature controls that incorporate environmentally friendly liquid-filled sensing elements
- Constant differential throughout the entire range
- Unaffected by cross ambient conditions
- Variety of sensing element styles
- Compact enclosure
- Fixed differential (case compensated)
- Line voltage mechanical thermostat
- +/- 2 deg F temperature sensitivity
- Screwdriver slot range adjuster
- Remote sensing capability
Product Details
Johnson Controls Penn Temperature Control, Series: A19, 15 A at 120 VAC, 3 A at 240 VAC Full Load, 120/208/240 VAC, Configuration: SPDT, Switching Action: Open/Close on Rise, 1 Stages, 10 ft Capillary Length, Sensing Element: Bulb, 6 A Full Load and 36 A Locked Rotor at 120 VAC, 3.4 A Full Load and 20.4 A Locked Rotor at 208 VAC, 3 A Full Load and 18 A Locked Rotor at 240 VAC, 10 A Non Inductive at 24 - 277 VAC, 125 V-A at 24 - 277 VAC Pilot Duty Contact, 1 -Switch, 3.5 deg F Differential, Temperature Settings: 25 - 255 deg F, Flat Surface Mounting, Galvanized Steel Enclosure, Gray, 2-1/8 in L, 4-3/8 in H, 1-13/16 in W, 275 deg F
Attributes
Amperage Rating: 15 A at 120 VAC, 3 A at 240 VAC Full Load
Capillary Length: 10 ft
Color: Gray
Configuration: SPDT
Contact Rating: 6 A Full Load and 36 A Locked Rotor at 120 VAC, 3.4 A Full Load and 20.4 A Locked Rotor at 208 VAC, 3 A Full Load and 18 A Locked Rotor at 240 VAC, 10 A Non Inductive at 24 - 277 VAC, 125 V-A at 24 - 277 VAC Pilot Duty
Differential Temperature: 3.5 deg F
Height: 4-3/8 in
Length: 2-1/8 in
Material: Galvanized Steel Enclosure
Mounting Type: Flat Surface
Number of Switches: 1
Sensing Element: Bulb
Series: A19
Stages: 1
Switching Action: Open/Close on Rise
Temperature Rating: 275 deg F
Temperature Settings: 25 - 255 deg F
Voltage Rating: 120/208/240 VAC
Width: 1-13/16 in
Features
- A19 Series controls are single-stage temperature controls that incorporate environmentally friendly liquid-filled sensing elements
- Constant differential throughout the entire range
- Unaffected by cross ambient conditions
- Variety of sensing element styles
- Compact enclosure
- Fixed differential (case compensated)
- Line voltage mechanical thermostat
- +/- 2 deg F temperature sensitivity
- Screwdriver slot range adjuster
- Remote sensing capability
